The RT-BE86U boasts dual-band WiFi 7 technology, achieving blazing-fast speeds of up to 6800 Mbps, ensuring seamless streaming, gaming and data-intensive tasks. Whether you’re binge-watching your favorite shows or collaborating in a virtual meeting, this router delivers.
Advanced 160 MHz Channels
The RT-BE86U unleashes the full potential of the ultrawide 160 MHz channels, delivering ultra-fast data transfer rates, reduced latency, and enhanced performance for a smoother network experience.
Comprehensive MLO Support
Multi-Link Operation (MLO) enables buffering-free connection by intelligently combining and switching between the 2.4 GHz and 5 GHz bands. ASUS RT-BE58U is built for the future of all WiFi 7 devices, regardless of the MLO mode they use*.
Multi-Gig Network
Unlock Next-gen 10G Network
The RT-BE86U comes with a 10G port and four 2.5G ports that combine for up to 20G of blistering WAN and LAN capacity. Advanced network configurations are made easy with Multi-WAN auto detection, convenient mobile tethering backup via USB and powerful VLAN controls.
Legacy Performance, Evolved
The RT-BE86U builds upon the legacy of the RT-AX86U with WiFi 7 technology, delivering superior network performance and exceptional reliability. Equipped with high-power front-end modules, the external antennas eliminate WiFi dead zones while providing consistent coverage in all directions. This 7-stream design enhances throughput and expands coverage, while the detachable antennas can be repositioned to better suit your specific needs, such as overcoming walls or other interference.
Next-gen Powerhouse
The RT-BE86U boasts a powerful quad-core 2.6 GHz CPU which increases processing power by up to 30%* for lightning-fast responsiveness, accelerated data transfers and an optimized gaming experience. It can also handle the most demanding networking scenarios, such as 10G connections or advanced network security.
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
Product Segment
BE6800 ultimate BE performance : 1032+5764 Mbps
WiFi Data Rate
WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
WiFi 7 (802.11be) (5GHz): up to 5764 Mbps
Antenna
External antenna x 3； Internal antenna x 1
Transmit / Receive
2.4GHz 3x3
5GHz 4x4
Processor
2.6GHz quad-core processor
Memory
256 MB Flash and 1 GB RAM
Boosts Speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth
Operating Frequency
2.4 GHz
5 GHz
Operating Mode
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode
I/O Ports
1 x 10G for WAN/LAN, 1 x 2.5G for WAN/LAN, 3 x 2.5G for LAN, USB 3.2 Gen1 x1, USB 2.0 Gen1 x1
Buttons
WPS Button, Reset Button, Power Switch, LED on/off Button
LED Indicator
WAN x1
10G Port x1
LAN x4
USB x1
2.4GHz x1
5GHz x1
Power x1
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 5 A current ； 19.5 V with max. 2.31 A current
Package Content
RT-BE86U WiFi router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card
Product Dimensions
235*90*316 mm
Game
Mobile Game Mode
Gear Accelerator
OpenNAT (Game Profile)
Gaming Port
Parental Control
Web & Apps Filters
Time Scheduling
Safe Browsing
• Maximum Parental Control Profile : 64
• Maximum Parental Control Content Cilter Rule : 64
Guest Network
"You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings."
Support Guest Network Pro
• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 5
Guest Network Connection Time Limit
Guest Network Pro Encryption : Open system, WPA/WPA2-Personal/WPA3-Personal
Security
AiProtection
VPN
WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, WPA3 Enterprise, Open System & OWE
DNS-over-TLS
Security Scan
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection Pro
VPN
Instant Guard
Yes
VPN Client WireGuard
VPN Server WireGuard
VPN Fusion
Support Surfshark
Traffic Control
Adaptive QoS
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
• Traffic Analysis Period : Daily, Weekly, Monthly
WAN
Internet Connection Type :
• PPPoE
• PPTP
• L2TP
• Automatic IP
• Static IP
• IPSec
WAN Aggregation
• Maximum Port Forwarding Rule : 64
• Maximum Port Triggering Rule : 32
NAT Passthrough :
• PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• SIP Pass-Through
• PPPoE Relay
LAN
LAN Link Aggregation
• Maximum Manually Assign IP Address Rule : 128
Wireless
MU-MIMO
• Maximum MAC Filters : 64
USB application
File System :
• HFS+
• NTFS
• vFAT
• ext2
• ext3
• ext4
User Interface
WEB: ASUSWRT
APP: ASUS Router APP
Administration
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
