技術規格
網路技術標準
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
產品規格
AX6000 ultimate AX performance : 1148+4804 Mbps
傳輸量
802.11a：最高 54 Mbps
802.11b：最高 11 Mbps
802.11g：最高 54 Mbps
802.11ax (2.4GHz)：最高 1148 Mbps
802.11ax (5GHz)：最高 4804 Mbps
天線
External antenna x 6
傳送 / 接收
2.4GHz 4x4
5GHz 4x4
處理器
2.0 GHz quad-core processor
記憶體
256 MB Flash
512 MB RAM
網速提升
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth
運作頻率
2.4GHz / 5GHz
Operating Mode
Wireless router mode
Access point mode
Media bridge mode
網路埠規格
RJ45 for 2.5 Gigabits BaseT for WAN x 1,
RJ45 for 2.5 Gigabits BaseT for LAN x 1,
RJ45 for Gigabits BaseT for LAN x 4,
USB 3.2 Gen 1 x 1,
按鈕
WPS Button, Reset Button, Power Button
LED 指示燈
Power x 1
WiFi x 1
1G LAN x 4
2.5G WAN x 1
2.5G LAN x 1
電源規格
AC Input : 100V~240V (50~60Hz)
DC Output : 12 V with max. 2.5 A current
包裝內容物
TUF Gaming AX6000 Dual Band WiFi 6 router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card
產品淨重(g)
696g
Product Dimensions
301.02 x 174 x 216 mm
獨家AiMesh技術
AiMesh
Primary AiMesh router
AiMesh node
遊戲加速
有
Mobile Game Mode
家長貼心管理
Parental Control
Safe Browsing
Parental Control Customized Internet schedule
Guest Network
Guest Network
• Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3
Security
AiProtection
WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
VPN
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
網路流量控制
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
-- Maximum Traditional QoS Rule : 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
• Traffic Analysis Period : Daily, Weekly, Monthly
Website history
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
WAN Aggregation
3G/4G LTE dongle
Port forwarding
• Maximum Port Forwarding Rule : 64
Port triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
LAN
DHCP Server
有
IPTV
LAN Link Aggregation
Manually assign IP address
• Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
其他無線功能
UTF-8 SSID
WiFi MAC address filter
• Maximum MAC Filters : 64
Wireless scheduler
Airtime fairness
RADIUS Server
Universal beamforming
Explicit beamforming
USB埠應用
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges
管理功能
Configuration backup and restore
Diagnosis tools
Feedback system
System log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
