Model
TUF Gaming BE3600 (TUF-BE3600)
Network Technology Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
Product Specifications
BE3600 ultimate BE performance: 688+2882 Mbps
Data Rate
802.11ax (5GHz): up to 2402 Mbps
WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
Antenna
External antenna x 4
Transmit / Receive
2.4GHz 2x2
5GHz 2x2
Processor
2.0 GHz quad-core processor
Memory
256 MB Flash
1 GB RAM
Network Speed Enhancement
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth
Operating Frequency
2.4GHz / 5GHz
2.4 GHz
5 GHz
Operating Mode
Wireless router mode
Access point mode
Media bridge mode
Network Port Specifications
RJ45 for 2.5 Gigabits BaseT for WAN x 1,
RJ45 for Gigabits BaseT for LAN x 4,
USB 3.2 Gen 1 x 1,
Buttons
WPS Button, Reset Button, Power Button
LED Indicators
Power x 1
WAN x 1
LAN x 1
2.4GHz WiFi x 1
5GHz WiFi x 1
Power Specifications
AC Input: 100V~240V (50~60Hz)
DC Output: 12 V with max. 2 A current
Package Contents
TUF Gaming BE3600 Dual Band WiFi 7 router
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card
Product Net Weight(g)
561g
Product Dimensions
274 x 168 x 205 mm
Exclusive AiMesh Technology
AiMesh
Primary AiMesh router
AiMesh node
Gaming Acceleration
Yes
Mobile Game Mode
Parental Care Management
Parental Control
Safe Browsing
Parental Control Customized Internet schedule
Guest Network
Guest Network
• Maximum Guest Network Rule: 2.4GHz x3, 5GHz x3
Security
AiProtection
WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter: 64
• Maximum Firewall Network Service Filter: 32
• Maximum Firewall URL Filter: 64
AiProtection
AiProtection
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
VPN
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Network Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
-- Maximum Bandwidth Limiter Rule: 32
Traditional QoS
-- Maximum Traditional QoS Rule: 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
• Traffic Analysis Period: Daily, Weekly, Monthly
Website history
WAN
Internet connection Type: PPPoE, PPTP, L2TP, Automatic IP, Static IP
3G/4G LTE dongle
Port forwarding
• Maximum Port Forwarding Rule: 64
Port triggering
• Maximum Port Triggering Rule: 32
DMZ
DDNS
NAT Passthrough: PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
LAN
DHCP Server
Yes
IPTV
Manually assign IP address
• Maximum Manually Assign IP Address Rule: 64
Wake on LAN (WOL)
Other Wireless Features
UTF-8 SSID
WiFi MAC address filter
• Maximum MAC Filters: 64
Wireless scheduler
Airtime fairness
RADIUS Server
Universal beamforming
Explicit beamforming
USB Port Applications
File System: HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges
Management Functions
Configuration backup and restore
Diagnosis tools
Feedback system
System log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
